EN-WP-C

  • EN-WP-C-1
  • EN-WP-C-3
  • EN-WP-C-2

FEATURES:

  1. Injection for PC housing(round)and PC cover offering IP65 protection against moistrue and dust,and an impact rating of IK08,inside 6063 aluminium reflector.
  2. No closing clips for cover and housing,cost saving,installation easy.
  3. Easyfor wire connection at back side of the housing.
  4. LED-based provides energy efficient solution and reduces maintenance costs.


APPLICATION:
Car parks,Industrial areas,Offices,Corridors,Supermarkets and Shops,Bakeries,Storage areas etc.

en-wp-c

ITEM CODE VOLTAGE/
FREQUENCY		 WATTAGE LED CCT LUMENS CLIP'S QTY
(PCS)		 DIMENSION(mm)
L*W*H		 ITEM/BOX
(PCS)		 CARTON SIZE(mm)
EN-WP-C-106 220-240V∽50/60HZ 10W 60pcs SMD2835 0.2W 3000K/4000K/6000K 900lm N/A 580*60*66 12 630*280*235
EN-WP-C-112 220-240V∽50/60HZ 18W 96pcs SMD2835 0.2W 3000K/4000K/6000K 1620lm N/A 1140*60*66 12 1190*280*235
EN-WP-C-115 220-240V∽50/60HZ 24W 120pcs SMD2835 0.2W 3000K/4000K/6000K 2160lm N/A 1480*60*66 12 1530*280*235
EN-WP-C-206 220-240V∽50/60HZ 18W 48pcs SMD2835 0.5W 3000K/4000K/6000K 1620lm N/A 580*75*66 9 630*250*235
EN-WP-C-212 220-240V∽50/60HZ 36W 90pcs SMD2835 0.5W 3000K/4000K/6000K 3240lm N/A 1140*75*66 9 1190*250*235
EN-WP-C-215 220-240V∽50/60HZ 50W 120pcs SMD2835 0.5W 3000K/4000K/6000K 4500lm N/A 1480*75*66 9 1530*250*235
